Twin Screw Barrel
● Pipes extrusion ● Sheets extrusion
● Profiles extrusion ● Compounding extrusion
● PVC / UPVC / RPVC / CPVC / WPC / SPC / HDPE / PP
● Filler percentage with 30-50%, 50-100%, 100-150%, 150-200%, 200-300%, more than 300%
You Need Better Twin Screw Barrel at Good Price!
- Product Detail
HUACHEN Screw has been a leading Twin Screw Barrel manufacturer in Zhoushan Jintang since 1993. Our twin screw barrels come in parallel, conical, anisotropic, and co-rotating designs. Customers have more options for wear and corrosion resistance with SKD insert sleeve barrels and plasma welded alloy screw barrels. Our company has also successfully exported and supplied twin screw barrels to customers worldwide.
Parallel Twin Screw Barrels Advantages
- – Excellent plasticization, high productivity, low shear force, stable pressure, less wear and tear, and low cost.
- – Superior at feeding powders, and ideal for heat-stable plastics and mixed plastics.
Compared to Single Screw Barrel,
- -Better at compounding polymers, venting, and self-cleaning.
Compared to Conical Twin Screw Barrels,
- – Parallel twin screw barrels are commonly used to process PVC products, especially over 350kg/h, due to their cost-efficiency and advanced design.
Conical Twin Screw Barrel Advantages
- – Offers efficient plasticization and mixing, high output, stable quality, a wide range of applications, and direct extrusion of PVC powders.
- – Suitable for extruding PVC pipes, plates, sheets, and profiles, compounding and pelletizing various filler formulation PVC powders.
Applications
Used in PVC sheets, pipes, profiles, and pellets. Solves issues like low foaming, high foaming, high filler formulation, wear, and corrosion. We offer a wide range of twin screw barrels for:
- 1. Solid wall PVC pipe extrusion machine;
- 2. PVC sheet extrusion machine;
- 3. PVC profile extrusion machine;
- 4. PVC compounding granulating machine;
- 5. UPVC pipe, CPVC pipe extrusion machine;
- 6. Corrugated wall PVC / PE / PP pipe extrusion machine.
We can supply counter-rotating twin screw barrel replacement parts for the following twin screw extrusion brands: ARGOS, APX, Battenfeld, Busano, Kabra, Mikrosan, KraussMaffei/KMD, Theysohn, TTS, Weber, Windsor, Cincinnati, Jwell, and more. >>Contact our engineer for your twin screw barrel
Popular Parallel Twin Screw Barrel Stock Models
| Extrusion brand | Screw barrel model |
|---|---|
| CINCINNATI | AGROS – 72 / 93 / 114 / 136 |
| KRAUSS MAFFEI | KMD – 75 / 90 / 110 / 130 |
| BATTENFIELD | BEX – 65 / 68 / 90 / 92 / 107 / 130 |
| KABRA | 52 / 65 / 68 / 90 / 92 / 110 / 135 / 168 |
| WINDSOR | KTS – 52 / 65 / 71 / 91 / 110 / 135 |
Fast Customisation Support
| φ52/25 | φ60/25 | φ75/36 | φ90/36 | ||
| φ107/28 | φ107/28 | φ120/26 | φ130/28 | ||
| φ135/28 | φ160/33 |
Popular Parallel Conical Twin Screw Barrel Stock Models
| 35/75 | 38/76 | 45/97 | 45/100 | 50/105 | 51/105 | 55/110 | 55/120 |
| 58/125 | 60/125 | 63/130 | 65/120 | 65/132 | 72/150 | 80/143 | 80/156 |
| 80/173 | 92/188 | 110/220 |
| Extrusion brand | Screw barrel model |
|---|---|
| Jinhu / Jinhailuo | SJZS screw barrel |
| Jwell | SJZS screw barrel |
| CINCINNATI | CM screw barrel, CMT screw barrel, KONOS screw barrel |
| KRAUSS MAFFEI | KMD screw barrel |
| WERBER | CE screw barrel |
| DAVID STANDARD | GC screw barrel |
Product Features
- 1. Parallel twin screw diameters available: 35 mm to 110 mm
- 2. Parallel twin screw L/D ratio available: 15 to 36
- 3. Conical twin screw model available: 45/100, 51/105, 55/110, 55/120, 65/132, 80/156, 80/173, 92/100, 110/200
- 4. Based materials: Premium 38CrMoAlA, UNS K24065, SACM645, 41CrAlMo7-10, SKD
- 5. Plasma nitriding surface hardness: HV1000-1100
- 6. Plasma nitriding depth: ≥ 0.7mm
- 7. Alloy deepness: 4-6mm
- 8. Alloy surface hardness: HRC≥61
>>Learn more about our twin screw barrels parameters here.
The Ultimate Solution for Abrasion and Wear:
- 1. Alloy steel of high strength, tempered and nitride.
- 2. bimetallic twin screw: plasma alloy coating spraying with nickel-based and molybdenum-based alloys on vulnerable screw parts with a thickness of 1 to 1.5 mm. Effectively provide 1.5 times longer service life.
- 3. screw with hard chrome plating as an optional process.
- 4. bimetallic barrel: barrel with bimetallic groove feed sleeve
- 5. Alloy sleeve barrel: barrel insert with SKD sleeve
>>Learn more about our bimetallic twin screw barrels treatments here.
Production Time
Stork model in 7 days. Peak season lead time: 45 days, off season lead time: 33 days
How to Order from HUACHEN Screw
Ready to enhance your production with HUACHEN’s advanced twin screw barrels? Follow our detailed Step-by-Step Guide to Order from HUACHEN Screw for a seamless purchasing experience.
For inquiries or more information about our twin screw barrels, please contact us.
About HUACHEN Screw
Since 1993, HUACHEN Screw has been a leading manufacturer of parallel twin screw barrels in Zhoushan, China. As a pioneer in designing and processing parallel twin screw extruder spare parts, we offer a wide range of services, including drawing rebuilding, design, modification, and custom screw barrels. Our products are trusted globally for their durability and efficiency. If you have any questions, please feel free to contact us.
